HP 7100 - Monitor Panel (Associate-Facing Display (AFD))

Monitor panel (Associate-Facing Display (AFD))
Description Spare part number
Display, associate-facing (AFD), 15 inch capacitive 667839-001
Display, associate-facing (AFD), 15 inch resistive 667838-001
Display, associate-facing (AFD), 17 inch capacitive 667841-001
1. Prepare the computer for disassembly (Preparation for disassembly on page 19).
2. Remove the rear I/O panel (
Rear I/O panel on page 22).
3. Open the top access door (
Opening the top access door on page 24).
4. Disconnect the monitor panel DisplayPort cable (1) and power cable (2).
28 Chapter 4 Removal and replacement procedures
