HP 8559A User Manual

MODEL 8559A
OPERATION
SECTION Ill
OPERATION
3-1. INTRODUCTION
3 - 2.
This section provides operating information
for the HP
8559A Spectrum Analyzer plug - in. It also
provides a brief description of display mainframe
controls. For a detailed description of the display
mainframe, refer to its manual.
3
- 3.
The HP
8559A Spectrum Analyzer plug - in can
be used with either the 180
- series display mainframes
or the HP
853A Spectrum Analyzer Display main -
frame.
3-4. DESCRIPTION
3-5. H P 8559A Spectrum Analyzer
3 - 6.
The HP
8559A employs harmonic mixing to
cover a measurement range of 10 MHz to 21
GHz in
six frequency bands. It can display frequency spans
as narrow as
100 kHz, and as wide as 9 GHz (the
latter in full span mode). A five
- digit LED readout
indicates the spectrum analyzer center frequency
with a resolution of 1 MHz. The HP
8559A can be
used to measure signals over an amplitude range of
- 11 1 dBm to + 30 dBm.
3-7.
HP 853A Spectrum Analyzer Display
3 - 8. The HP 853A Spectrum Analyzer Display is a
large
- screen, digital storage display mainframe for
use exclusively with the HP
8559A, 8558B, and
8557A Spectrum Analyzer plug - ins. Digital memory
provides buffer storage for two independent traces,
both of which can be displayed or blanked as
desired. Digital processing also provides push
- button
features such as maximum signal hold, digital aver
-
aging, and trace normalization. A conventional ana -
log display mode can also be selected.
3
- 10. The HP 853A has limited HP - IB capabilities.
CRT trace and graticule data is dumped directly to a
listen
- only HP - IB plotter by pressing two front - panel
push buttons. Control settings on the spectrum
ana -
lyzer plug - in cannot be monitored via the HP - IB;
however, all digital display functions are program
-
mable via a controller, and two lines of annotation
can be displayed on the CRT for labelling purposes
or operator prompting. In addition, controller com
-
mands allow transfer of trace data for analysis or
storage.
3-1 1. CONTROLS, INDICATORS, AND CON -
NECTORS
3-1 2. Control Grouping
3 - 13. The Spectrum Analyzer plug - in and Display
mainframe front
- panel controls fall into three gen -
eral groups: those that deal with the display, those
that deal with frequency, and those that deal with
amplitude. These controls are shown in Figure 3
- 1
and accompanied by detailed explanations of their
use.
3 - 14. Display. The display group consists of:
SWEEP
TIME/DIV VIDEO FILTER
SWEEP TRIGGER BASELINE CLIPPER
VERT POSN HORIZONTAL
POSI-
TION
VERT GAIN INTENSITY
MANUAL SWEEP FOCUS
HORIZ GAIN (rear TRACE ALIGN
panel of HP
8559A)
3 - 15.
The display group enables the operator to cal
-
ibrate the display and to select a variety of scan and
display conditions. However, when the SWEEP
TIME/DIV Control is placed in the AUTO position,
sweep time is controlled by the RESOLUTION BW,
FREQ
SPAN/DIV, and VIDEO FILTER controls.
3 - 16. Frequency. The frequency group consists
of:
TUNING
FREQUENCY BAND
GHz
ALT IF
SIG IDENT
RESOLUTION BW
FREQ
SPAN/DIV

HP 8559A Specifications

General

Brand	HP
Model	8559A
Category	Measuring Instruments
Language	English
