HP 8559A - 8-64

SERVICE MODEL 8559A
(08565 - 60090)
YIG - TUNED OSCILLATOR FIRST MIXER 3 dB ATTENUATOR
ASSEMBLY A6 ASSEMBLY
AT1
R E A R Y I G S E C O N D C O N V E R T E R F R O N T Y I G MIXER A16W2
MOUNTING BRACKET ASSEMBLY A5 MOUNTING BRACKET SUPPORT BRACKET (08559 - 60061)
(08559
- 00036) (08559 - 00035) (08559 - 00013)
FIGURE
&24. RF SECTION, COMPONENT LOCATIONS
