HP 8560E - Table 4-5 Assembly Mounting (See Figure 4-1)

Chapter 4 241
Replaceable Parts
Firmware-Dependent Part Numbers
Figure 4-1 Parts Identification, Assembly Mounting
Table 4-5 Assembly Mounting (see Figure 4-1)
Item HP Part
Number
Qty Description Mfr
Code
Mfr Part
Number
1 0515-1349 11 SCREW-MACH M3 X 30MM-LG PAN-HD TORX 28480 0515-1349
2 0515-2310 3 SCREW-MACH M3 X 60MM-LG PAN-HD TORX 28480 0515-2310
3 0515-2308 2 SCREW-MACH M3 X 100MM-LG PAN-HD TORX 28480 0515-2308
4 0515-2332 10 SCREW-MACH M3 X 6MM-LG PAN-HD TORX 28480 0515-2332
4 0515-0664 2 SCREW-MACH M3 X 12MM-LG PAN-HD TORX 28480 0515-0664
