CARD
-+
DISPLAY
CARD
-+
DLP
CARD
+
STATE
Card
+
Trace
Requires Option 003 for an HP 85901, HP
8592L,
or HP 8594L.
recalls into spectrum analyzer memory a display image saved on the memory
card. It does not recall the associated instrument state, but the restored
display can be viewed and copied. Before recalling a display that was saved
under a prefix other than the current prefix, change the current prefix to the
prefix used when the display was saved.
The intensity of some screen items may differ if the current spectrum analyzer
state does not match the state of the recalled image. This will not affect the
spectrum analyzer ability to output a copy of the screen.
It is possible to have more functionality than just viewing and copying a
recalled display image. For example, you can set the spectrum analyzer to the
identical window configuration as when the display was saved. Then recall
the trace that corresponds to the display image. This will restore the trace
and state information. Finally, you can recall the display image. At this point,
markers and display line can be used to examine the data. If an attempt is
made to update the trace data, the display will be erased and redrawn to
reflect the current instrument state.
Pressing LOAD FILE is an alternate way to load display image from the
memory card into spectrum analyzer memory. See “Saving and Recalling Data
from the Memory Card” in Chapter 5 for more information.
Front-Panel Key Access:
@ZiJ
Requires 0ption 003 for an HP 85901, HP 85921, or HP 8594L.
recalls into the spectrum analyzer memory a downloadable program (DLP)
saved on the memory card. Before recalling data that was saved under a prefix
other than the current prefix, change the current prefix to the prefix used
when the data was saved. Pressing LOAD FILE is an alternate way to load
program data from the memory card into spectrum analyzer memory. See
“Saving and Recalling Data from the Memory Card” in Chapter 5 for more
information. See also the Change Prefix
softkey
description.
Front-Panel Key Access:
L-1
Requires Option 003 for an HP 85901, HP
8592L,
or HP 8594L.
recalls into spectrum analyzer memory a state saved on the memory card.
CARD
4
STATE also displays the time and date when the state data was
stored. Before recalling a state that was saved under a prefix other than the
current prefix, change the current prefix to the prefix used when the state was
saved.
If the windows display mode is being used, the instrument state can only be
recalled into the active window.
Pressing LOAD FILE is an alternate way to load state data from the memory
card into spectrum analyzer memory. See “Saving and Recalling Data from the
Memory Card” in Chapter 5 for more information.
Front-Panel Key Access:
cm’
Requires Option 003 for an HP
859OL,
HP
8592L,
or HP 8594L.
recalls into spectrum analyzer memory a trace saved on the memory
card. Limit lines and amplitude correction factors are recalled by pressing
Card
+
Trace, LIMIT LINES or AMP COR. If the screen title does not
exceed 34 characters, the time and date when the trace data was stored is
also displayed with the recalled trace data. The screen title and date are
not recalled with limit-line files or amplitude correction factor files. Before
recalling a trace, limit-line file, or amplitude correction factors file that was
Key Descriptions 7-15
