HP 8590 E-Series User Manual

r
COf’Y UEV PRNT PLT
r
PLTS/Pc, 1 2 4
Figure 6-15. Plot Configure Menu
4. Referring to Figure 6-15 select the plotter configuration for your spectrum analyzer by
pressing the appropriate keys:
5. Configure your analyzer to plot to the LaserJet by pressing:
pmiq
Press this key to bring up the configuration menu.
COPY DEV PRNT PLT
so that PLT is underlined.
PLTS/PG 1 2 4
Press this key to underline the number of plots per page desired.
Choose
1,
2,
or
4
plots per
page (see Figure
6-2.
PLT Cl
LOC _
If two plots per page are chosen, this function allows you to select
the location on the paper for the plotter output. The upper and
lower sections of the softkey label graphically represent where the
plotter output will be located.
Press the softkey until the rectangular marker is in the desired
section of the softkey label.
PLT Cl-
I.Jc - -
If four plots per page are chosen, this function allows you to select
the location on the paper for the plotter output. The quadrant of
the softkey label graphically represents where the plotter output will
be located.
Press the softkey until the rectangular marker is in the desired
section of the softkey label.
PLT->LJT ON OFF
Press this key so that ON is underlined.
Icopv) Press this key to plot the spectrum analyzer display to the LaserJet
printer.
6.22 Printing and Plotting
