To Save Limit-Line
Yhbles
or Amplitude Correction Factors
The procedure for saving limit-line tables or amplitude correction factors is similar to saving
trace data. State and trace data is not recalled when the limit-line tables or amplitude
correction factors are recalled.
1. Press
CD’SPLAY)
or
C-1,
Change Prefix to enter a new prefix or change the existing
prefix.
If you do not specify a prefix, the limit-line table will be saved with a file name consisting of
I-(register
number). A table of amplitude correction factors will be saved with a file name
consisting of a-(register number).
2. When saving tables, set up the table to be stored. See
“Using the Limit-Line Functions” or
“Using Amplitude Correction Functions
for more information about entering data.
2.
Press
(SAVE_).
If INTERNAL is underlined, press INTERNAL CARD to select CARD. Press
Trace
4
Card to access the menu with LIMIT LIMES and AMP COR .
4.
Press either LIMIT LINES , to save limit-line tables, or AMP COR , to save
amplitude-
correction factors. REGISTER # and PREFIX= are displayed on the spectrum analyzer
display.
5. Use the numeric keypad to enter a register number and then press
Cm).
The data is saved with a file name consisting of a “1” (for limit-line tables) or “a” (for
amplitude-correction factors), the prefix that was entered, an underscore (-), and the
register number.
To Recall Limit-Line
Tables
or Amplitude Correction Factors
l.
Use Change Prefix to enter the prefix, or use the existing prefix.
2.
press
[RECALL).
If INTERNAL is underlined, press INTERNAL CARD to select CARD.
3.
Press Card
+
Trace to access the menu with LIMIT LINES and AMP COR
4.
Press either LIMIT LINES , to recall a limit-line table, or AMP COR , to recall
amplitude-correction factors.
5. Enter the register number that the limit-line data or amplitude-correction factors was saved
under and then press (ENTER).
Note
If LOAD FILE is used to recall limit-line files or amplitude-correction factor
files, the traces are set to the store-blank mode. Press
[TRACE),
CLEAR WRITE A
to view trace A data, or press
[PRESET).
Using Analyzer Features 5-15
