Measuring Impedance using the Smith Chart
Enter the Measurement Parameters
Press the following keys on the analyzer:
( or )
NOTE This example measurement uses the default instrument parameters for
an S
11
measurement. If your particular measurement requires different
parameters (such as frequency range, source power level, number of data
points, and sweeptime) enter them now.
Perform a User Two-Port Calibration
Refer to the section “Measuring S-Parameters using a Two-Port
Calibration” on page 3-19 for examples of how to perform a user two-port
calibration.
NOTE If you are testing a one-port device, refer to the section “Perform a User
One-Port Calibration” on page 3-49 for an example of how to perform a
one-port calibration.
PRESET
User Preset
Factory Preset
MEAS 1
S11 Refl Port1
FREQ
Center
175
MHz
Span
200
MHz
