HP 8712ES - To Use Polar Format Markers; To Use Smith Chart Markers

ES User’s Guide 4-27
Using Instrument Functions
Using Markers
To Use Polar Format Markers
The analyzer displays the polar marker values as magnitude and phase.
You can use these markers only when you are viewing a polar display
format. The polar format is accessed by pressing .
To Use Smith Chart Markers
In Smith chart format, markers have a resistive value, a reactive value,
and a complex impedance value. The Smith chart format is accessed by
pressing . For information on interpreting
Smith chart values, see “Measuring Impedance using the Smith Chart”
on page 3-73.
FORMAT
Polar
FORMAT
Smith Chart
