HP 8712ES - Page 358

8-52 ES User’s Guide
Hardkey/Softkey Reference
M
M
Softkey in the more format menu. Displays choices for various
magnitude units for the y-axis scale.
Access Keys:
Softkey in the directory utilities menu. Displays the character entry
menu for entry of the directory name.
See “To Use Directory Utilities” on page 4-65 for more information.
Access Keys:
Softkey in the menu. This softkey is only available when using
internal or external broadband detectors. Compensates for detector
drift one time when selected. When your external RF source is at the
detectors, this is the recommended setting to coordinate RF off and
zeroing.
Softkey in the add max line, add min line, add max point, and add min
point menus. Adds a marker to the data trace and allows it to be moved
to identify trace frequencies and amplitudes.
Access Keys: ,
or or or
Hardkey in the CONFIGURE area. Displays the menu to set markers,
use marker search and delta markers.
See “Using Markers” on page 4-3 for more information.
Softkey in the marker functions menu. Changes the center frequency
to that of the active marker and modifies the frequency span
accordingly. If markers are off, it first turns on marker #1 at its
previous setting or at the center frequency (default).
Access Keys:
Mag Units
FORMAT
More Format
Make Directory
SAVE RECALL
File Utilities
Directory Utilities
Manual Zero
CAL
Marker
DISPLAY
Limit Menu
Add Limit
Add Max Line
Add Min Line
Add Max Point
Add Min Point
MARKER
Marker
−
>
Center
MARKER
Marker Functions
