8-76 ES User’s Guide
Hardkey/Softkey Reference
S
Softkey in the amplifier, broadband passive, and measurement menus.
Selects the S
22
(reverse reflection) type of measurement. Power is
output from the analyzer’s port 2 and also measured there.
See “Measuring S11 Reflection Port 1 using a One-Port Calibration” on
page 3-48 for more information on a similar (S
11
) measurement.
Access Keys: or . Also , or
Softkey in the custom colors menu. Use this key to customize the colors
of display items on your external monitor. Saturation is the amount of
pure color (selected with the key) to be mixed with white.
Saturation values are expressed as a percentage: 0 to 100%, with 0
representing no color, and 100 representing no white.
See “Using an External VGA Monitor” on page 4-87 for more
information.
Access Keys:
Softkey in the define save menu. Selects which measurement channel's
(1 or 2) trace data is to be saved in ASCII format for output. Also
allows you to choose whether to save in Lotus 123 or Touchstone
format for spreadsheet use.
See “Saving and Recalling Measurement Results” on page 4-55 for
more information.
Access Keys:
Softkey in the programs menu. Titles the current program AUTOST
and saves it to internal RAM or a 3.5” disk as set by . At
power-up, the network analyzer searches the internal non-volatile
RAM disk and the floppy disk in the analyzer’s built-in disk drive for
an AUTOST (auto-start) file, loads it, and executes it if present.
Access Keys:
MEAS 1 MEAS 2 BEGIN
DISPLAY
SAVE RECALL
SAVE RECALL
