3-16 ES User’s Guide
Making Measurements
Using the BEGIN Key to Make Measurements
If measurement channel 2 is active when the key is used to
select a new device type, measurement channel 2 is turned off, and
measurement channel 1 is made active.
If measurement channel 2 is active when the key is used to
select a new measurement type, measurement channel 2 will be left on
and active. However, the analyzer then proceeds to set up channel 1 for
the requested measurement type, even though channel 2 is the active
channel.
Using the BEGIN Key to Configure
Measurements
This procedure shows you how to configure the network analyzer for
measurements.
1. Press ( or ). Presetting
the instruments puts it into a known state with predefined
parameters.
2. Press and then use a softkey to select the type of device that
you will be measuring (amplifier, filter, broadband passive device,
mixer, or cable—Option 100 only).
3. Connect your test device to the network analyzer.
4. Use the softkeys to select the type of measurement you want to make:
Press , , , or
if you want to measure a particular
S-parameter. (S-parameter selections are under the ,
, , and menus.)
Press if you want to measure the RF power of a device.
(The selection is under the menu.)
Press if you want to measure the conversion
loss of a device. (The selection is under the
menu.)
Press (Option 100 only) if you want to measure the
structural return loss of a cable. (The selection is under the
menu.)
BEGIN
BEGIN
PRESET
User Preset
Factory Preset
BEGIN
S11 Refl Port1
S21 Fwd Trans
S12 Rev Trans
S22 Refl Port2
Amplifier
Filter
Broadband Passive
Mixer
Power
Power
Amplifier
Conversion Loss
Conversion Loss
Mixer
SRL
SRL
Cable
