1-16 ES User’s Guide
Installing the Analyzer
Step 4. Configure the Analyzer
Installing the Analyzer in a Rack
Use only the recommended rack mount kit (Option 1CM when ordered
with the analyzer or HP part number 08712-60036 when ordered
separately) with this instrument; it needs side support rails. Do not
attempt to mount it by the front panel (handles) only. This rack mount
kit allows you to mount the analyzer with or without handles.
To install the network analyzer in an HP 85043D rack, follow the
instructions in the rack manual.
CAUTION To install the network analyzer in other racks, note that they may
promote shock hazards, overheating, dust contamination, and inferior
system performance. Consult your HP customer engineer about
installation, warranty, and support details.
CAUTION VENTILATION REQUIREMENTS: When installing the product in a
cabinet, the convection into and out of the instrument must not be
restricted. The ambient temperature (outside the cabinet) must be less
than the maximum operating temperature of the instrument by 4° C for
every 100 watts dissipated in the cabinet. If the total power dissipated in
the cabinet is greater than 800 watts, then forced convection must be
used.
Place other system instruments (computer, printer, plotter) where
convenient, within the HP-IB cable length limits (see Table 1-1) or other
interface cabling limits.
