2-4 ES User’s Guide
Getting Started
Entering Measurement Parameters
Entering Measurement Parameters
This section describes how to input measurement parameter information
into the network analyzer.
NOTE When entering parameters, you can use the numeric key pad, as
described in each example, or you can use the keys or the
front panel knob to enter data.
NOTE When you are instructed to enter numeric values in this manual, it often
can get cluttered and confusing to depict each key stroke. So in this
manual, numbers (no matter how many characters) are depicted inside
one keycap. For example, if you are instructed to enter the number −42.5,
it will be depicted inside one keycap like this: . To enter this
number, the following keys need to be pressed in succession:
.
You can follow along with these examples by connecting the filter and
cable that were supplied with your instrument as shown in Figure 2-2.
Figure 2-2 Connect the Filter to the Analyzer
−
− 4 2
5
