ES User’s Guide 2-5
Getting Started
Entering Measurement Parameters
Presetting the
Analyzer
Press the key and then press either or
. The key returns the analyzer to
user-defined preset settings you may have saved as file UPRESET.STA.
If this file doesn’t exist, you can create it by following the instructions in
the pop-up message that appears when the key is pressed. When the
key is pressed, the following major default conditions
apply:
1. Preset power level can be set to other than 0 dBm if desired.
See “Entering Source Power Level” on page 2-6 for more
information.
NOTE The measurement parameters that you enter will be retained in the
analyzer's memory when the power is turned off, and will be restored
when the power is turned back on.
NOTE Refer to Chapter 11, “Factory Preset State and Memory Allocation,” for a
comprehensive table of factory preset conditions.
Frequency range (HP 8712 ES) 0.3 to 1300 MHz
Frequency range (HP 8714 ES) 0.3 to 3000 MHz
Power level
1
0 dBm
Measurement Channel 1
measurement
S
21
Forward Transmission
Measurement Channel 2
measurement
Off
Format Log Magnitude
Number of points 201
Sweep time Auto
Scale 10 dB/div
Reference 0 dB
System Bandwidth Medium wide
PRESET
