ES User’s Guide 1-5
Installing the Analyzer
Step 2. Meet Electrical and Environmental Requirements
2. Ensure the available ac power source meets the following
requirements:
If the ac line voltage does not fall within these ranges, an
autotransformer that provides third-wire continuity to ground should
be used.
3. Ensure the operating environment meets the following requirements
for safety:
• indoor use
• altitude up to 15,000 feet (4,572 meters)
• temperature 0 °C to 55 °C
• maximum relative humidity 5 to 95 percent relative at +40 °C
(non-condensing)
CAUTION This product is designed for use in Installation Category II and Pollution
Degree 2 per IEC 1010 and 664 respectively.
NOTE The above requirements are for safety only. Separate conditions that
must be met for specified performance are noted in Chapter 9.
Nominal
Setting
AC Line Power
115 V
230 V
90 to 132 Vac (47 to 63 Hz)
198 to 264 Vac (47 to 63 Hz)
