HP 8712ET User Manual

ES User’s Guide 1-15
Installing the Analyzer
Step 4. Configure the Analyzer
probably not necessary. To change the recognized
address, press
.
NOTE Only one hardcopy HP-IB address can be set at a time. Changing the
printer address, for example, changes the plotter to the same address.
Analyzer: Press ,
, or .
The network analyzer's address will appear (the
default is 16). To change the address, press
.
To Configure
Peripheral
Settings
If your system uses serial or parallel peripherals, follow the guidelines
below to configure the system. Refer to the peripheral's manual for
correct cables and settings. The parallel and serial ports have standard
Centronics DB-25 and RS232 pinouts respectively as explained in
Chapter 7.
Serial
Devices: Press . Use the
entry controls to highlight your type of printer or
plotter, and press . If the baud rate or
handshake at the top of the screen are incorrect, use
the softkeys to change them.
Parallel
Devices: Press . Use the
entry controls to highlight your type of printer or
plotter, and press .
LAN
Printer: Press . Use the
entry controls to highlight HP LaserJet PCL5/6
PCL5 LAN, and press . If the printer IP
address at the top of the screen is incorrect, press
to enter the correct IP address.
NOTE When is selected, the first two lines in the box at
the top of the display screen show the current settings.
NOTE Use a PCL5 printer for fastest hardcopies. See “Configure the Hardcopy
Port” on page 4-71for more information.
Print/Plot HP-IB Addr
number
Enter
SYSTEM OPTIONS
HP-IB
HP 8712ES Address
HP 8714ES Address
number
Enter
HARDCOPY
Select Copy Port
Select
HARDCOPY
Select Copy Port
Select
HARDCOPY
Select Copy Port
Select
LAN Printr IP Addr
Select Copy Port
