27
| Change The HyperTerminal's Baudrate Accordingly |
|---------------------------<Baudrate Available>---------------------------|
|<1> 9600(Default)* |
|<2> 19200 |
|<3> 38400 |
|<4> 57600 |
|<5> 115200 |
|<0> Exit |
============================================================================
Enter your choice(0-5):5
The following messages appear:
Baudrate has been changed to 115200 bps.
Please change the terminal's baudrate to 115200 bps, press ENTER when ready.
NOTE:
Typically the size of a .bin file is over 10 MB. Even at 115200 bps, the download takes about 30
minutes.
3. Select Call > Disconnect in the HyperTerminal window to disconnect the terminal from
the router.
Figure 2 Disconnect the terminal connection
NOTE:
If the baud rate of the console port is 9600 bps, jump to step 9.
4. Select File > Properties, and in the Properties dialog box, click Configure.
