A-Class System Overview and Reference
A-Class Server - System Overview
Chapter 1
10
A-Class Server - System Overview
The A-Class server is a compact addition to the HP9000 server family, targeted at the
ISP server market. The A-Class server design allows the use of existing qualified
peripherals and I/O add-in options. It is a PCXL-2 (PA-7300 RISC Processor) based
platform designed to support the UNIX Internet Service Provider (ISP) market.
System Hardware Overview
A-Class server hardware has the following characteristics:
• It has a two rack unit height that makes it suitable for racked (up to 20 per rack) or
stand-alone installations.
• It comes configured with one (1-way) 180 MHz. PA-7300 RISC Processor. An
additional (optional) 1Mb of 2nd-level cache is available.
• It has eight RAM memory slots that can use 128, 256 or 512MB memory modules.
• There are two I/O slots each capable of handling either PCI or HSC add-in cards.
One slot is Access Port (AP) card capable.
• The embedded disk bay is capable of supporting 2 single-ended type-1 SCSI drives.
• The server supports the following core I/O functions:
One 10/100 Base-T port supports connection to the primary LAN.
One 10 Base-T Port supports connection to the integrated web-based console.
One 9-Pin RS-232 port supports connection to an ASCII console.
The internal SCSI bus is available externally to connect additional single-ended
Type-1 SCSI devices.
System Software Overview
A-Class servers require the HP-UX 10.20 or 11.0 operating system with an Independent
Peripheral Release (IPR) date of October 1998 (9810) or later.
NOTE HP-UX is the only supported operating system for A-Class servers.
