A-Class Server Installation
Installing Internal Add-On Components
Chapter 2
43
A-Class servers provide 2 slots for Cache Memory. The following rules govern the
installation memory in A-Class Servers.
• Cache Memory must be installed in SIMM pairs.
• The capacity of SIMMs must be the same.
Follow the steps below to install Cache Memory in A-Class servers.
Electrostatic Discharge Precautions.
The procedures in this section require opening the server and exposing the system to
electrostatic discharge. Always observe all electrostatic precautions when working with
components inside or out of the server. Failure to follow these precautions may result in
component damage or loss of system reliability.
• Use a grounding mat and an anti-static wrist strap.
• Wear the anti-static wrist strap to ensure that any accumulated electrostatic charge
is discharged from your body to ground.
Before You Do Anything...
• Power down the system.
• Unplug the server.
NOTE Cabinet-mounted servers must be removed from the cabinet before proceeding.
• Remove the top of the server by unscrewing the knurled captive screws on each side
of the rear of the server. Slide the top back, lift it off, and set it aside.
Step 1. Install the first 512MB Cache Memory SIMM in either unoccupied slot.
Step 2. Install the second 512MB Cache Memory SIMM in the remaining unoccupied slot.
Step 3. Proceed to A-Class Server Power Up and Boot Procedures.
Installing Embedded Disk Drives.
This section describes how to install embedded disk drives into A-Class servers.
Abbreviated embedded disk drive installation instructions also appear on the 11” x 14”
maintenance label adhered to the bottom of the top cover.
A-Class servers support up to two embedded disk drives. As of April 2000, disk capacities
of 4GB, 9GB and 18GB are supported.
Follow the steps below to install embedded disk drives in A-Class servers.
Electrostatic Discharge Precautions.
The procedures in this section require opening the server and exposing the system to
electrostatic discharge. Always observe all electrostatic precautions when working with
components inside or out of the server. Failure to follow these precautions may result in
component damage or loss of system reliability.
