A-Class Server Installation
Installing Internal Add-On Components
Chapter 2
44
• Use a grounding mat and an anti-static wrist strap.
• Wear the anti-static wrist strap to ensure that any accumulated electrostatic charge
is discharged from your body to ground.
Before You Do Anything...
• Power down the system.
• Unplug the server.
NOTE Cabinet-mounted servers must be removed from the cabinet before proceeding.
• Remove the top of the server by unscrewing the knurled captive screws on each side
of the rear of the server. Slide the top back, lift it off, and set it aside.
Step 1. Remove the disk carrier by removing the slotted T15 TORX screw and slide the disk
carrier upward and toward the power supply.
Step 2. If an embedded disk is already installed, disconnect the power and data cables from that
disk. Place the disk carrier on a ESD safe mat.
Step 3. Set address and configuration jumpers on the disk to be installed. The lower disk is
usually the boot disk and the recommended address is 6. The upper disk is recommended
to be address 5. DO NOT use address 7 as this address is reserved for the SCSI
controller internal to the server. The SCSI controller address of 7 can not be modified.
Step 4. Check configuration jumpers existing disks. Make sure the TERMINATION ENABLED
jumper is removed.
NOTE The TERMINATION ENABLED jumper must be REMOVED on all
embedded disk drives. Failure to remove this jumper will prevent
the SCSI bus from operating properly. Symptoms include failing to
boot from the embedded disk drives when external devices are
connected to the “SCSI (Single Ended) 8/16/5 path”.
