A-Class System Service
Replacing an A-Class Server Exchange Base Unit (EBU)
Chapter 3
105
The integrated A-Class Web Console will require reconfiguring. Follow the Chapter 2,
“A-Class Server Installation,” on page 21 instructions in the A-Class Server Power Up
and Boot Procedures section to complete this task.
When the replacement server is powered up and selftest has successfully completed, you
will be prompted to enter the LAN Station Address. This is a one-time prompt that only
occurs during the initial system configuration.
The terminal will display: WARNING: The system LAN Station Address has not been
set.
The System LAN Station Address is not set.
WARNING: The LAN Station Address can be set one time only.
Set now [Y/N]?
Type Y and press
Enter. The “LAN Station Address” value is located on the
rear of the system.
Do not enter the value for the “Web Console MAC Address”.
NOTE As it appears on the rear label, the LAN Station Address does not include a hyphen (-).
However, a hyphen is required (for example: xxxxxx-xxxxxx) when entering the LAN
Station Address at this prompt.
This action cannot be undone.
Confirm LAN Station address 0060b0-83c41b [Y/N/Q(uit)]? Type Y and press
Enter.
The terminal will display: The system has been initialized with LAN Station
Address 0060b0-83c41b.
NOTE The system will reset itself, re-run selftest, and perform a normal power-on selftest.
The replacement server is now ready to continue normal boot and power-up procedures.
