A-Class Server Installation
Cabinet-Mounted A-Class Server System Unpack and Install
Chapter 2
30
WARNING Wear protective glasses while cutting the plastic bands around the shipping
container. These bands are under tension. Failure to heed this warning can
result in serious eye injury if the bands snap back and hit you in the face when
cut.
Step 1. Cut the plastic polystrap bands around the shipping container.
Step 2. Lift the cardboard top cap off of the shipping box (callout 1) and remove the packing
material underneath (callout 2). Remove the screws that secure the ramps in place and
lift the ramps out (callout 3).
1
2
3
3
3
