HP A5120 EI Series

12
Figure 9 Attach the front brackets to the rack
1 2
3
4
5
6
(1) Load-bearing screw
(2) Rear mounting bracket
(3) Front panel
(4) A screw used to fasten the front mounting bracket to the rack
(5) Front mounting bracket
(6) Front square-holed post
