Table 7-1 System Board Connections (continued)
No. System Board Connector System Board Label Color Component
14 Hood Lock HLCK black USB Device, such as a Media Card
Reader
15 Hood Sensor HSENSE white Hood Sensor
16 USB MEDIA2 black Second Media Card Reader
17 PCI Express x1 X1PCIEXP1 black Expansion Card
18 PCI Express x16 downshifted
to a x4
X4PCIEXP white Expansion Card
19 PCI Express x16 X16PCIEXP black Expansion Card
20 PCI PCI1 white Expansion Card
System Board Connections 137
