Item Description Spare part number
(1) Access panel 646819-001
(2) Front bezel
For use in 8300 models 689380-001
For use in 8380 models 689381-001
Bezel blank (5.25-inch, optical drive; not illustrated) 570838-001
Bezel blank (3.5-inch; not illustrated) 583653-001
(3) Power supply
320W, 90% efficient 613764-001
320W, standard 613765-001
(4) System board (includes replacement thermal material)
For use in models without Windows 8 657096-001
For use in models with Windows 8 Standard 657096-501
For use in models with Windows 8 Professional 657096-601
Memory modules (PC3-12800, 1666-MHz; not illustrated)
8-GB 689375-001
4-GB 671613-001
2-GB 671612-001
Processors (include replacement thermal material; not illustrated)
Intel Core i7 3770 (3.4-GHz, 8-MB L3 cache) 688164-001
Intel Core i5 3570 (3.4-GHz, 6-MB L3 cache) 688162-001
Intel Core i5 3470 (3.2-GHz, 6-MB L3 cache) 687943-001
Intel Core i3 2130 (3.4-GHz, 3-MB L3 cache) 665120-001
Intel Core i3 2120 (3.3-GHz, 3-MB L3 cache) 638629-001
Intel Pentium G870 (3.1-GHz, 3-MB L3 cache) 691936-001
Intel Pentium G860 (3.0-GHz, 3-MB L3 cache) 665123-001
Intel Pentium G640 (2.8-GHz, 3-MB L3 cache) 691935-001
32 Chapter 4 Illustrated parts catalog
