Expansion cards
GeForce GT630 PCIe x16 graphics card, 2 GB
nVidia Quadro NVS315 PCIe x16 graphics card, 1 GB
nVidia Quadro NVS310 PCIe x16 graphics card, 512 MB
AMD Radeon HD8490 PCIe x16 graphics card, 1 GB
AMD Radeon HD8470 PCIe x16 graphics card, 1 GB (for use only in China)
AMD Radeon HD8450 PCIe x16 graphics card, 1 GB
AMD Radeon HD8350 DH PCIe x16 graphics card, 1 GB (for use only in China)
AMD R9 255 graphics processor, 2 GB
AMD R7 240 graphics processor, 2 GB
Intel PRO/1000 NIC
PCIe to M.2 adapter
128 GB, M.2 SSD (for use with PCIe to M.2 adapter)
The computer has two PCI Express x1 expansion slots, one PCI Express x16 expansion slot, and
one PCI Express x16 expansion slot that is downshifted to a x4 slot.
NOTE: You can install a PCI Express x1, x8, or x16 expansion card in the PCI Express x16 slot.
For dual graphics card configurations, the first (primary) card must be installed in the PCI Express
x16 slot that is NOT downshifted to a x4.
To remove, replace, or add an expansion card:
1. Prepare the computer for disassembly (
Preparation for disassembly on page 32)
2. Remove the access panel (
Access panel on page 33)
Expansion cards 39
