Power supply
Description
Power supply, 280W, 92% efficient
Power supply, 280W, 90% efficient
Power supply, 280W, 85% efficient (for use only in China)
Power supply, 280W, standard
1. Prepare the computer for disassembly (Preparation for disassembly on page 32).
2. Remove the access panel (
Access panel on page 33).
3. Remove the four silver Torx T15 screws that connect the power supply to the chassis.
60 Chapter 5 Removal and replacement procedures – Microtower (MT) chassis
