HP Engage Go Mobile System Service Manual

Cable matrix for HP Engage Go Convertible System with
advanced I/O connectivity base and standalone printer
Cables
(1) Printer 24 V PUSB power and data Y cable (4) Printer serial data cable
(2) Advanced I/O connectivity base 180 W AC power cord (5) Advanced I/O connectivity base USB Type-C cable
(3) Printer 24 V PUSB power cable
IMPORTANT: Connect either the 24 V PUSB power and data Y cable (1) or the 24 V PUSB power cable (3) and serial data cable (4)
between the I/O connectivity base and the printer. Do not connect all three.
Cable matrix for HP Engage Go Convertible System with advanced I/O connectivity base and standalone
printer
13

HP Engage Go Mobile System Specifications

General

Display	1920 x 1280
Memory	8 GB
Storage	128 GB
Operating System	Windows 10 IoT Enterprise
Connectivity	Wi-Fi, Bluetooth
Ports	headphone/microphone combo
Security	fingerprint reader
