Hand strap
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 37).
2. Lift the hand strap up (1).
3. Slide the screw covers (2) on each side of the hand strap back and then up. Remove the screws (3) that
secure the strap to the mobility head unit.
To replace the hand strap, reverse the removal procedures.
38 Chapter 6 Removal and replacement procedures for the mobility head unit
