HP Engage Go Mobile System Service Manual

System board callouts
Sys Bd Label Color Component Sys Bd Label Color Component
WLAN Gold WLAN module NFC White NFC module
WWAN Gold WWAN module FPR White Fingerprint reader
SPK Black Speakers LCM Black Display
POWER White Power button POGO Black POGO connector
SIM White SIM board SSD Black M.2 SSD drive
TOUCH White
Display
Sys Bd Label Color Component Sys Bd Label Color Component
CN2251 Black Front-facing webcam MIC ALS Black Webcam light
CN2250 Black Rear-facing webcam
48 Chapter 6 Removal and replacement procedures for the mobility head unit

HP Engage Go Mobile System Specifications

General

Display	1920 x 1280
Memory	8 GB
Storage	128 GB
Operating System	Windows 10 IoT Enterprise
Connectivity	Wi-Fi, Bluetooth
Ports	headphone/microphone combo
Security	fingerprint reader
