HP Engage Go Mobile System Service Manual

5. Connect the ngerprint reader cable to a USB Type-A port on the I/O connectivity base.
6. Reconnect the I/O connectivity base and power cords.
Mounting the HP Engage Go Convertible System to a countertop
You can use an optional countertop mounting bracket to mount the mobility system’s column to a countertop.
NOTE: The mounting bracket requires an 80 mm hole in the countertop. The thickness of the countertop
must be 10 mm to 50 mm.
1. If the dock’s stability base is attached to the column, remove the screw on the underside of the column
(1), and then remove the base (2) from the column.
34 Chapter 5 Hardware congurations and upgrades

HP Engage Go Mobile System Specifications

General

Display	1920 x 1280
Memory	8 GB
Storage	128 GB
Operating System	Windows 10 IoT Enterprise
Connectivity	Wi-Fi, Bluetooth
Ports	headphone/microphone combo
Security	fingerprint reader
