Removing the integrated MSR from the mobility head unit
1. Turn o the mobility system properly through the operating system, and turn o any external devices.
2. Disconnect the power cord from the mobility system.
IMPORTANT: Regardless of the power-on state, voltage is always present on the system board as long
as the system is plugged into an active AC outlet. You must disconnect the power cord and wait
approximately 30 seconds for the power to drain to avoid damage to the internal components of the
system.
3. Insert a at-blade screwdriver between the MSR and the mobility head unit, and then disengage the
MSR (1). Tilt the MSR (2) up slightly and pull the MSR (3) from the USB Type-C port and clips.
IMPORTANT: To avoid damaging the MSR and/or the mobility head unit, be sure to follow these
instructions when removing the MSR.
Removing the integrated MSR from the mobility head unit 25
