HP ESA-E Series - Page 366

Conversion Guide 75
HP 8590/HP ESA Spectrum Analyzers Conversion Guide
APPENDIX
KSA
KSB
KSC
KSD
KSE
KSG
KSH
KSM
KSO
KSZ
KSc
KSi
KSl
KSm
KSn
KSo
KSp
dBm amplitude units
dBmV amplitude units
dBµV amplitude units
Volt amplitude units
Screen title
Video average on
Video average off
Marker noise
Marker value to span
Reference level offset
Trace A plus trace B into trace A
Exchange trace B and C
Trace B into trace C
Graticule off
Graticule on
Annotation off
Annotation on
AUNITS DBM
AUNITS DBMV
AUNITS DBUV
AUNITS V
TITLE
VAVG ON
VAVG OFF
MKNOISE
MKSP
ROFFSET
APB
BXC
BTC
GRAT OFF
GRAT ON
ANNOT OFF
ANNOT ON
L0 Display line off DL OFF
M1
M2
M3
MA
MC
MT0
MT1
Marker off
Marker normal
Marker delta
Marker amplitude
Marker count
Marker track off
Marker track on
MKOFF
MKN
MKD
MKA?
MKFC
MKTRACK OFF
MKTRACK ON
O1
O2
O3
O4
Output format, in real number format
Output format, in binary format, two bytes (word) per
element
Output format, in measurement data format
Output format, in binary format, 1 byte per element
TDF P
TDF B;MDSW
TDF M
TDF B;MDS B
Alternate
Commands Description
HP 8590 Series
Command
