 [type <trunk | fec | lacp>] - Determines the method by which the switch
distributes the traffic load across the multiple links in the trunk group: trunk - uses
source and destination MAC addresses for load distribution (select this to connect to
devices such as the HP Switch 2000 or the Sun Trunk Server); fec - uses an
automatic protocol for load distribution (select this to connect to devices that
support Cisco's Fast EtherChannel trunking).
2.10 Spanning Tree
2.10.1 Spanning Tree commands - EXEC level
show spanning-tree config
Displays spanning tree configuration information.
Output Format:
Switch Configuration - Spanning Tree Operation
Spanning Tree Enabled [No] : No
STP Priority [32768] : 32768 Hello Time [2] : 2
Max Age [20] : 20 Forward Delay [15] : 15
Port
----
Type Cost Pri Mode | Port Type Cost Pri Mode
-------- + ----- --- ---- | ---- -------- + ----- --- ----
10/100TX | 10 128 Norm | 9 10/100TX | 10 128 Norm
10/100TX | 10 128 Norm | 10 10/100TX | 10 128 Norm
10/100TX | 10 128 Norm | 11 10/100TX | 10 128 Norm
10/100TX | 10 128 Norm | 12 10/100TX | 10 128 Norm
10/100TX | 10 128 Norm | 13 10/100TX | 10 128 Norm
10/100TX | 10 128 Norm | 14 10/100TX | 10 128 Norm
10/100TX | 10 128 Norm | 15 10/100TX | 10 128 Norm
25
