3.1.3 Module Information
HP ProCurve Switch xxxxx 01-Apr-2000
==========================- CONSOLE - MANAGER MODE -============================
Status and Counters - Module Information
Slot Module Type Module Description
----
A Slot Available
B Slot Available
C Slot Available
D Slot Available
E Slot Available
F Slot Available
G Slot Available
H Slot Available
Actions-> Back Help
Return to previous screen.
Use up/down arrow keys to scroll to other entries, left/right arrow keys to
change action selection, and <Enter> to execute action.
3.1.4 Port Status
HP ProCurve Switch xxxxx 01-Apr-2000
==========================- CONSOLE - MANAGER MODE -============================
Port Type
----
1 10/100TX
2 10/100TX
3 10/100TX
4 10/100TX
5 10/100TX
6 10/100TX
7 10/100TX
8 10/100TX
9 10/100TX
10 10/100TX
Status and Counters - Port Status
Intrusion Flow Bcast
Alert Enabled Status Mode Ctrl Limit
No Yes Up 100HDx off 0
No Yes Down 10HDx off 0
No Yes Down 10HDx off 0
No Yes Down 10HDx off 0
No Yes Down 10HDx off 0
No Yes Down 10HDx off 0
No Yes Down 10HDx off 0
No Yes Down 10HDx off 0
No Yes Down 10HDx off 0
No Yes Down 10HDx off 0
Actions-> Back Intrusion log Help
Return to previous screen.
Use up/down arrow keys to scroll to other entries, left/right arrow keys to
change action selection, and <Enter> to execute action.
47

HP Procurve 2524 Specifications

General

Switching Capacity	8.8 Gbps
Layer	Layer 2
Rack Mounting	Yes
MAC Address Table Size	8000 entries
Jumbo Frame Support	No
Power Supply	Internal
Management	CLI, SNMP
Operating Temperature	0°C to 40°C
Operating Humidity	15% to 95% non-condensing
Ports	24 x 10/100 + 2 x 10/100/1000
