Fan
Description
Fan
Fan, non-recycled
1. Prepare the computer for disassembly (Preparation for disassembly on page 25).
2. Remove the access panel (
Access panel on page 26).
3. From the outside, rear of the chassis, remove the three Phillips screws that secure the fan to the
chassis.
4. From the inside of the chassis, disconnect the fan control cable (1) from the system board connector
labeled CHFAN2.
60 Chapter 5 Removal and replacement procedures: Microtower
