System board
NOTE: All system board spare part kits include replacement thermal material.
NOTE: System board appearance may vary.
Description
System board for use in models without Windows 8.1
System board for use in models with Windows 8.1 Standard
System board for use in models with Windows 8.1 Professional
System board for use in models with NetClone (the People’s Republic of China only)
1. Prepare the computer for disassembly (Preparation for disassembly on page 25).
2. Remove the access panel (
Access panel on page 26).
3. When replacing the system board, make sure the following components are removed from the defective
system board and installed on the replacement system board:
●
Memory modules (Memory on page 29)
●
Expansion cards (
Expansion cards on page 32)
●
Fan sink (
Fan sink on page 54).
●
Processor (
Processor on page 56)
4. Disconnect all cables connected to the system board, noting their location for reinstallation.
5. Remove the eight Torx T15 screws that secure the system board to the chassis.
