HP ProDesk 400 G2 User Manual

Table 6-5 Computer Setup—Advanced (for advanced users) (continued)
Bus Options Allows you to enable or disable:
●
PCI SERR# Generation. Default is enabled.
●
PCI VGA Palette Snooping, which sets the VGA palette snooping bit in PCI configuration space; only
needed when more than one graphics controller is installed. Default is disabled.
Device Options Allows you to set:
●
Turbo Mode (enable/disable). Allows you to enable and disable the Intel Turbo Mode feature, which
allows one core of the system to run at a higher than standard frequency and power if other cores
are idle. Default is enabled.
●
Num Lock State at Power-On (off/on). Default is off.
●
Integrated Video (enable/disable). Use this option to disable the integrated video controller when
another video controller is present in the system. Default is enabled.
●
Internal Speaker (does not affect external speakers). Default is enabled.
●
Multi-Processor (enable/disable). Use this option to disable multi-processor support under the OS.
Default is enabled.
●
USB3.0 BIOS Driver Support (enable/disable). Use this option to disable USB 3.0 ports.
VGA Configuration Displayed only if there is an add-in video card in the system. Allows you to specify which VGA controller
will be the “boot” or primary VGA controller.
Option ROM Launch
Policy
Let you set the launch policy for option ROMs. An Option ROM typically consists of firmware that is called
by the system BIOS. For example, an adapter card that controls a boot device might contain firmware that
is used to connect the device to the system once the Option ROM is loaded.
●
PXE Option ROMs (legacy only/EFI only/do not launch)
●
Video Option ROMs (legacy only/EFI only)
Recovering the Configuration Settings
This method of recovery requires that you first perform the Save to Removable Media command with the
Computer Setup (F10) Utility before Restore is needed. (See
Computer Setup—File on page 75 in the
Computer Setup—File table.)
NOTE: It is recommended that you save any modified computer configuration settings to a USB flash media
device and save the device for possible future use.
To restore the configuration, insert the USB flash media device with the saved configuration and perform the
Restore from Removable Media command with the Computer Setup (F10) Utility. (See
Computer Setup—File
on page 75 in the Computer Setup—File table.)
82 Chapter 6 Computer Setup (F10) Utility

HP ProDesk 400 G2 Specifications

General

Tcase	72 °C
Bus type	DMI2
Stepping	C0
Processor cache	2 MB
Processor cores	2
Processor model	G1840
System bus rate	5 GT/s
Processor family	Intel® Celeron® G
Processor series	Intel Celeron Processor G1000 Series for Desktop
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	2.8 GHz
Processor cache type	L2
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor operating modes	32-bit, 64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	54, 53 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333 MHz
Memory bandwidth supported by processor (max)	21.3 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	2x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	1 x 4 GB
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	No
Total storage capacity	500 GB
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics
Maximum on-board graphics card memory	1.024 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Power supply	180 W
Product type	PC
Market positioning	Business
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Horizontal
Sustainability certificates	ENERGY STAR
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Scalability	1S
Processor code	SR1VK
Processor ARK ID	80800
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, SSE4.2
Thermal solution specification	PCG 2013C
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Intel segment tagging	Enterprise, Small Business

Weight and Dimensions

Depth	358.8 mm
Width	165 mm
Height	355 mm
Weight	6500 g
