Error messages 124
Unsupported power supply detected in bay X
Audible Beeps: 1 long, 1 short
Possible Cause: The power supply in bay X is not supported by the server.
Action: Install a supported power supply in bay X.
For supported power supplies, see the server documentation on the HP website
(http://www.hp.com/support
).
Unsupported Processor Detected System will ONLY boot ROMPAQ Utility. System
Halted.
Audible Beeps: 1 long, 1 short
Possible Cause: Processor and/or processor stepping is not supported by the current system ROM.
Action: Refer to the server documentation for supported processors. If a ROM version exists that supports
the processor,
1. Power down the server.
2. Insert a Systems ROMPAQ diskette containing the latest ROM version.
3. Boot the system to flash the system to the latest ROM version. Allow 15 minutes for the process to
complete. Successful completion is indicated by a series of beeps of increasing pitch.
USB Tape-based One button Disaster Recovery (OBDR) drive detected.
<<Press F8 for configuration options>>
Select a configuration option:
1. Enable OBDR
2. Exit
Audible Beeps: None
Possible Cause: A USB tape device that supports One Button Disaster Recovery (OBDR) is installed in the
system.
Action:
1. Press 1 or 2.
o Pressing 2 exits the configuration.
o Pressing 1 starts the configuration. The following message appears
Attempting to enable OBDR for the attached USB tape drive...
2. Observe the configuration progress. The following error may appear:
Error - USB tape drive not in Disaster Recovery mode.
3. Follow the onscreen directions:
Remove power to USB drive and reboot.
The following message should appear:
OBDR is now enabled for the attached USB tape drive.
WARNING: A Type 2 Header PCI Device Has Been Detected...
The BIOS will not configure this card.
It must be configured properly by the OS or driver.
