HP ProLiant DL385 G7 - DIMM Removal and Installation

Removal and replacement procedures 65
QR 1066 MHz
3
— 3 SR SR 1333 MHz 1333 MHz 1066 MHz
3
— 3 DR DR 1333 MHz
DR 1066 MHz
1066 MHz 800 MHz
3
— 3 mixed SR 1333 MHz
DR 1333 MHz
DR 1066 MHz
1066 MHz 800 MHz
3
1 2 SR 1333 MHz
DR 1333 MHz
DR 1066 MHz
QR 1066 MHz
800 MHz 667 MHz
— *These are the only configurations supported by UDIMMs. All configurations listed in this table
are supported by RDIMMs.
— LVDIMM support is dependent on the ROM version.
— This table is for reference only. It may not be updated to reflect recent changes.
o 800 MHz—The memory bus speed is set to 800 MHz regardless of the quantity of memory modules
installed, unless the table above reflects a slower memory bus speed.
NOTE: There may be more than one memory bus speed menu option.
DIMMs
To remove the component:
1. Power down the server (on page 26).
2. Extend or remove the server from the rack ("Remove the server from the rack" on page 27, "Extend the
server from the rack" on page 27).
3. Remove the access panel ("Access panel" on page 33).
4. Remove the PCI riser cage ("PCI riser cage" on page 43).
5. Remove the air baffle ("Air baffle" on page 53).
