HP ProLiant DL385 G7 - Non-Hot-Plug PCI Riser Slot Definitions

Component identification 93
Non-hot-plug PCI riser board slot definitions
Secondary (slot -
form factor)
Primary (slot -
form factor)
PCIe2 riser slot
description
PCIe2 riser slot
description
PCIe2 x16
riser slot
description
PCIe2/PCI-X
riser slot
description
4 - FL/FH
1 - FL/FH PCIe2 x16
(8,4,2,1)
PCIe2 x16
(8,4,2,1)
PCIe2 x16
(16,8,4,2,1)
PCI-X 64 bit/100
MHz
5 - LP
2 - HL/FH PCIe2 x8 (4,2,1) PCIe2x16
(8,4,2,1)
— PCI-X 64 bit/100
MHz)
6 - LP
3 - HL/FH PCIe2 x8 (4,2,1) — — PCIe2 x8
(8,4,2,1)
Notes:
• "Primary" denotes the risers are installed in the primary riser connector.
• "Secondary" denotes the risers are installed in the secondary riser connector.
• Installing the risers listed in the table above in either the primary or secondary riser connectors
determines the form factor of the PCI cards supported by those risers.
• FL/FH denotes full-length, full-height. HL/FH denotes half-length, full-height. LP denotes low profile.
• The PCIe2 x16 riser supports a maximum power of 225W with an HP power cable. This cable must be
used for PCIe card wattages greater than 75W.
