Removal and replacement procedures 70
10.
Remove the power supply cage assembly.
To replace the component, reverse the removal procedure.
System board
To remove the component:
1. Power down the server (on page 26).
2. Remove all power supplies ("Hot-plug power supply" on page 31).
3. Remove the server from the rack (on page 27).
4. Remove the access panel ("Access panel" on page 33).
5. Remove the PCI riser cage ("PCI riser cage" on page 43).
6. Remove the battery pack ("Removing the battery pack" on page 49).
7. Remove the air baffle ("Air baffle" on page 53).
8. Remove the power supply backplane ("Power supply backplane" on page 37).
CAUTION: To prevent damage to the server or expansion boards, power down the server and
remove all AC power cords before removing or installing the PCI riser cage.
9. Remove the hot-plug fans from the fan cage ("Hot-plug fan" on page 35).
10. Remove the fan cage ("Fan cage" on page 54).
11. Remove all DIMMs ("DIMMs" on page 65).
