Component identification
Front panel components
Server with power module
Item Description
1 Box 1 — Supported options:
Eight-bay SFF HDD/SSD drive cage
Six-bay SFF HDD/Two-bay NVMe SSD (Premium) drive cage
Eight-bay SFF NVMe SSD drive cage (with only four NVMe drives
installed)
2 Box 2 — Supported options:
Eight-bay SFF HDD/SSD drive cage
Eight-bay SFF NVMe SSD drive cage
Six-bay SFF HDD/Two-bay NVMe SSD (Premium) drive cage
3 Box 3 — Supported options:
Eight-bay SFF HDD/SSD drive cage
Eight-bay SFF NVMe SSD drive cage
Six-bay SFF HDD/Two-bay NVMe SSD (Premium) drive cage
4 Front USB 30 port
Table Continued
106 Component identification
