Removing the bezel
Removing the CPU Mezzanine UPI performance kit
Procedure
1.
Power down the server.
2.
Remove all power:
a.
Disconnect each power cord from the power source.
b.
Disconnect each power cord from the server.
3.
Do one of the following:
•
Extending the server from the rack.
• Removing the server from the rack.
4.
Removing the access panel.
CAUTION: Do not operate the server for long periods with the access panel open or removed. Operating the server
in this manner results in improper airflow and improper cooling that can lead to thermal damage.
5. Remove the primary PCIe riser cage (Removing a primary PCIe riser cage).
6. Remove the CPU Mezzanine UPI performance kit.
Removal and replacement procedures
45
