Item Description
16 Energy pack connector 2 (processor mezzanine board)
2
17 Universal media bay USB/Display port connector
18 Intrusion detection switch connector
19 Power supply connectors (PS3, PS4)
20 Power supply connectors (PS1, PS2)
21 Secondary PCIe riser connector (processor 2 required)
22 System battery
23 Tertiary PCIe riser connector (processor 2 required)
24 TPM connector
25 microSD connector
1
The energy pack connected to this connector provides backup power to the DIMM slots and controllers installed on the system board.
2
The energy pack connected to this connector provides backup power to the DIMM slots on the processor mezzanine tray.
NOTE: This server supports only the HPE Smart Storage Battery.
System maintenance switch descriptions
Position
Default Function
S1
1
O
O = iLO security is enabled.
On = iLO security is disabled.
S2 O Reserved
S3 O Reserved
S4 O Reserved
S5
1
O
O = Power-on password is enabled.
On = Power-on password is disabled.
S6
1,
2,
3
O
O = No function
On = Restore default manufacturing settings
S7 O Reserved
S8 — Reserved
S9 — Reserved
S10 — Reserved
S11 — Reserved
S12 — Reserved
1
To access the redundant ROM, set S1, S5, and S6 to On.
