HP ProLiant DL580 Gen10 - Nvme Drive Cable Matrix

Option kit Cable part number* From To
Optical disk drive 869949-001
2
Component System board
Systems Insight Display Included with
component
Component System board
* To order spare cables, use the following kits and spare part numbers.
1
USB 30 Ext. 600mm+SASPWR BP cable kit (881699-001)
2
Optical drive cable (784623-001)
GPU kits
Option kit Cable part number* From To
HPE GPU 8p Keyed GPU Cable
Kit
869820-001
1
GPU Riser
HPE GPU 8p Cable Kit 869821-001
1
GPU Riser
* To order spare cables, use the following kits and spare part numbers.
1
GPU cables kit (875097-001)
NVMe drive cable matrix
Use the following tables to find supported NVMe drive configurations, cabling information, and part numbers.
NVMe drives are supported in servers with the following riser configurations:
• 6 slot primary
•
6 slot primary + 8 slot butterfly *
• 6 slot primary + 9 slot butterfly **
• 7 slot primary + 8 slot butterfly
•
4 port slimline primary + 8 slot butterfly + 4 port mezzanine card
• 4 port slimline primary + 9 slot butterfly + 4 port mezzanine card
* The 8 slot butterfly riser contains a 6 slot riser in the secondary PCIe slot, and a 2 slot riser in the tertiary PCIe slot.
** The 9 slot butterfly riser contains a 7 slot riser in the secondary PCIe slot, and a 2 slot riser in the tertiary PCIe slot.
Server riser configuration: 6 slot riser installed in the primary riser cage
# of NVMe
drives
supported
Processor
quantity
Cable part number * From To Power cable part
number *
2 1 869957-001
1
Drive box 2, 8SFF (6+2)
Premium drive cage
Primary 6 slot riser 870479-001
3
2 1 869957-001
1
Drive box 4, 2SFF Premium
drive cage
Primary 6 slot riser 870479-001
3
Table Continued
138 Cabling
