# of NVMe
drives
supported
Processor
quantity
Cable part number From To Power cable
part number
2 3 869957-001
1
Drive box 4, 2SFF Premium
drive cage
Butterfly 6 slot riser 870479-001
3
2 4 869957-001
1
Drive box 2, 8SFF (6+2)
Premium drive cage
Butterfly 6 slot riser 870479-001
3
2 4 869957-001
1
Drive box 4, 2SFF Premium
drive cage
Butterfly 6 slot riser 870479-001
3
4 4 869957-001
1
Drive box 2, 8SFF (6+2)
Premium drive cage
Butterfly 6 slot riser 870479-001
3
Drive box 4, 2SFF Premium
drive cage
Butterfly 6 slot riser
4 4 869957-001
1
Drive box 1, 8SFF (6+2)
Premium drive cage
Drive box 2, 8SFF (6+2)
Premium drive cage
Butterfly 6 slot riser 870479-001
3
Butterfly 6 slot riser
* To order spare cables, use the following kits and spare part numbers.
•
1
NVMe cable kit (877983-001)
•
2
NVMe cable kit (881703-001)
•
3
USB 30 Ext. 600mm+SASPWR BP cable kit (881699-001)
Server riser configuration:
•
Primary riser cage—4 port slimline riser installed
•
Butterfly riser cage—6 slot and 2 slot risers installed
•
4 port NVMe mezzanine card installed
# of NVMe
drives
supported
Processor
quantity
Cable part number From To Power cable
part number
16 3 870508-001
2
Drive box 2, 8-NVMe drive
cage
4 port mezzanine card 870479-001
3
Drive box 3, 8-NVMe drive
cage
Primary 4 port riser
Table Continued
Cabling 143
