HP Proliant DL580 - Removing the Front Bezel

Removal and replacement procedures 21
8. Remove all power supplies ("Removing a redundant hot-plug power supply"
on page 59
).
9. Loosen the thumbscrews, and lift the system cage from the server.
NOTE: The T-15 Torx screwdriver can be used to loosen the
thumbscrews. The T-15 Torx screwdriver is shipped with the server and
can be located on the rear panel ("Rear panel components" on page
98
).
Removing the front bezel
1. Power down the server ("Powering down the server" on page 18).
2. Extend the server from the rack.
3. Remove the access panel ("Removing the access panel" on page 19
).
4. Using the T-15 Torx screwdriver, remove the three screws on each side of
the front bezel.
