Removal and replacement procedures 33
5. Remove the PCI-X Hot Plug basket ("Removing the PCI-X Hot Plug basket"
on page 32
).
To replace the component, reverse the removal procedure.
Removing a non-hot-plug expansion board
1. Power down the server ("Powering down the server" on page 18).
2. Extend or remove the server from the rack ("Removing the server from the
rack" on page 19
).
3. Remove the access panel ("Removing the access panel" on page 19
).
4. Disconnect any required internal or external cables from the expansion
board.
5. Open the PCI latch.
6. Unlock the retaining clip.
